Operation Manual
Name Function
15 Progress Display
When a time-consuming process, such as reformulation of panoramic or
Cephalometric radiographic image is in progress, the processing progress is
displayed.
16 “Export” Button
Exports the image newly acquired or formulated by tomographic adjustment
asaleintheTIFFformat.Namesandexportstheloadeddata(RAWdata).
17 “OK” Button
Transfers the image newly acquired or formulated by tomographic
adjustmenttotheViewerandclosesthescreenofImageCreator.
18 “Cancel” Button
Closes the screen of Image Creator without transferring the image to the
Viewer.
19 “Drag & Drop” Button
The image formulated by a new acquisition or tomographic adjustment is
transferred to the viewer by the mouse’s drag and drop. By right-clicking
themouse,theformatofletobetransferredcanbechosenfromTiff8-bit,
Tiff 16-bit, DICOM 16-bit, and Trophy Windows Format 16-bit.
20 “Filter” check box
Whenchecked,theimageprocessinglterisappliedwhenpanoramicim-
ageisconstructed,andthesofttissuelterisappliedwhencephalometric
image is constructed. After image acquisition, the presence or lack thereof
isreectedonthepanoramicimagereconstructedbypressingthePreview
button. This function can also be applied to images acquired in the past.
21
"Optimize Panoramic Layer"
check box
When checked, the front tomographic position is optimized before
panoramic image construction, and the calculated information on the tomo-
graphic position is used in constructing the panoramic image. This function
can also be applied to images acquired in the past.
NOTE : When the "Filter" is applied, surroundings of parts which do not readily allow X-ray
penetration may appear dark due to the image processing. When the surrounding
area appears dark, it may appear like a secondary caries. In such a case, check
the image without the "Filter" applied.
4.5 Image Data
There are two kinds of acquired data: RAW data consisting of multiple strip-shaped frame
images, and image data (panoramic image and cephalometric image) constructed from RAW
data.TomographicpositioncanbechangedonRAWdata,butitslesizeislarge(approx.
900MB).AsforimagedataconstructedfromRAWdata,thelesizeissmall(approx.10MB),
but the tomographic position cannot be changed.
4.6 Saving and Loading of Acquired Data (RAW Data)
Call back Last Image
Image Creator automatically saves the data one acquired image only after its acquisition.
That image can be easily recalled using the Call back Last Image" function.
NOTE :When the computer is turned off or rebooted after image acquisition, the acquired
imageisloadedfromtheleandittakestimetoloadthedata.
: If another data is loaded after the data is acquired, it takes some time for the data
tobecalledbackastheacquireddataisloadedfromthele.
