4.8 Display Adjustment
By operating the Display Adjustment Buttons, the left-drag function of the mouse for the
Image Display area can be chosen.
Domain Button
DomainButtonisusedwhendeningarectangulardomainontheimageshownat
theImageDisplayarea.Arectangulardomainisdenedbythemouse’sleft-dragging
from the starting coordinates to the ending coordinates. Only one rectangular domain
can be set for the displayed image.
Window Level Button
Window Level Button is used when adjusting the window level of the image shown at
the Image Display area. Click and drag with the left mouse button to adjust.
Horizontal Movement Button
Horizontal Movement Button is used when moving the image shown at the Image
Display area horizontally. Click and drag with the left mouse button to adjust.
Zoom Button
Zoom Button is used when enlarging or reducing the image shown at the Image
Display area. Click and drag with the left mouse button to enlarge/reduce.
Reset Button
IfpressedwhenDomainButtonisselected,thedomaindenedbecomesunselected.
If pressed when Window Level Button is selected, the window level returns to the
default value.
If pressed when either Horizontal Movement Button or Zoom Button is selected, the
imagetsintotheImageDisplayarea.
Delete button
When pressed while a panoramic image is displayed, the “Call back Last Image”
screen is displayed.
Display adjustments can also be done with mouse movements only without using these
buttons.
Window Level Adjustment : Dragging the mouse while both right and left buttons pressed.
Horizontal Movement : Mouse’s right-drag
Zoom : Wheel movements
Window Level Reset : Mouse’s left double-click
Position and Zoom Reset : Mouse’s right double-click
