YOSHIDA XP73 - Page 133

Maintenance Services
131
Operation Manual
(4) Procedure
 1.SetthemeasurementrangeoftheMultimetertoAC(measurablerange0~300V).
2. Connect the Multimeter probe between both the polarities (L (line) - N (neutral) of
the power outlet.
*
1
: “with load” indicates such a condition that the elevating motor or rotating arm is
activated and/or X-ray is being irradiated.
6. Ground Protective earth
Check that the equipment has been connected to the correctly-grounded power outlet.
(1) Accuracy of a voltmeter (tester)
 ACVoltage±(0.7%+2digits)oritsequivalents
(2) Multimeter type
True RMS type
(3) Recommended Multimeters
 1.Fluke87V(Fluke)
2. PC510 (SANWA)
3. 3802 (HIOKI)
or their equivalents
(4) Procedure
1. Set the measurement range of the Multimeter to AC (measurable range 0 ~ 300
V).
2. Connect the Multimeter probe to L (line) or N (neutral) of the power outlet.
3. Check that the results described below have been obtained.
 (i)L-G(ground)voltage:AC90~AC132VorAC198~AC264V
7. QA (Quality Assurance)
Check the panoramic image of this equipment.
For equipment with 3D function, check the 3D image acquired as well.
See also: "12 QA (Quality Assurance)" P.187
* Caution
• To avoid electrical shock, be sure to read the instruction manual supplied with the Multi-
meter carefully prior to use.
