Before Using this Product
40
Operation Manual
6
Left-right slide
xingknob
Fixes the left-right sliding. Loosen to adjust the left-right position of
the forehead support.
7 Shaft
Holds up the forehead support. There are two marks on both sides
whichindicateFOVheight.Uppermarkshowstheupperendof
FOVandthelowermarkshowsthelowerendofFOV.
8
Up-down
positioning unit
Adjusts the attachment and height of bite plate.
9
Up-down lock
lever
Fixes the up-down positioning unit at the arbitrary height. Fixes by
clicking in the left-right position and cancels in the center position.
10 Headxatorlever
Headxatorleverxtheheadxatorfor3Dimageacquisitiontothe
chin rest.
NOTE :Attachtheheadxatorfor3Dimageacquisitionwhenacquiring3Dimage.An
error occurs for the following cases.
Description How to solve
X-ray Exposure switch is pressed without attaching the
headxatorfor3Dimageacquisitioninthe3Dimage
acquisition mode.
Warning messages (FL06) is displayed. Cancel the
error using the reset switch from the control panel.
Attachtheheadxatorfor3Dimageacquisition.
Theheadxatorfor3Dimageacquisitionisattached
other than in 3D image acquisition mode.
Warning messages (FL05) is displayed. Cancel the
error using the reset switch from the control panel.
Removetheheadxatorfor3Dimageacquisition.
