Page 150/169 AFNZPxxx – DUALACE2 NEW GENERATION – User Manual
Error code
Effect
Condition
Restart
procedure
MDI /
LED
CODE
CAN
OPEN
CODE
ZAPI
CODE
THERMIC SENS. KO
Maximum current is reduced
according to parameter MOT.T.
T.CUTBACK and speed is
reduced to a fixed value.
Start-up, stand-by,
running
61
4211
250
TH. PROTECTION
Traction controller reduces the
max current linearly from Imax
(85°C) down to 0 A (105°C)
Start-up, stand-by,
running
62
4210
62
BRAKE RUN OUT
Traction is stopped
Start-up, stand-by,
running
Traction/Pump
Request
63
FFCC
204
TILLER ERROR
Traction stopped, EB applied
Stand-by, running
Valves or
Traction/Pump
Request
64
FFB9
185
MOTOR TEMPERAT.
Maximum current is linearly
reduced (see paragraph 9.14)
and speed is reduced to a fixed
value.
Start-up, stand-by,
running
65
4110
65
MOTOR TEMP. STOP
EB is applied, Traction/Pump,
valves stopped
Start-up, stand-by,
running
65
FFB2
178
NO CAN MSG.
MC is opened, EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
request
67
8130
248
SENS MOT TEMP KO
Maximum current is reduced
according to parameter MOT.T.
T.CUTBACK and speed is
reduced to a fixed value.
Start-up, stand-by,
running
68
4311
218
SMARTDRIVER KO
MC is not closed, Traction/Pump,
valves stopped
Start-up
Key re-cycle
69
3302
193
EPS RELAY OPEN
Traction/Pump motor is stopped
Start-up, stand-by,
Running
Valves or
Traction/Pump
request
70
FFCD
205
WRONG RAM MEM.
MC is opened, EB is applied,
Traction/Pump, valves stopped
Stand-by
Key re-cycle
71
FFD2
210
DRIVER SHORTED
MC is opened (the command is
released), EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
request
74
3211
74
CONTACTOR DRIVER
MC is opened (the command is
released), EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
request
75
3221
75
COIL SHOR. MC
MC is opened, EB is applied,
Traction/Pump, valves stopped
Start-up
(immediately after
MC closing), stand-
by, running
Valves or
Traction/Pump
request
76
2250
223
VDC LINK OVERV.
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Stand-by, running
Valves or
Traction/Pump
request
77
FFCA
202
VACC NOT OK
Traction/Pump motor is stopped
Start-up, stand-by,
running
Traction/ request
78
FF4E
78
INCORRECT START
Traction/Pump motor is stopped
Start-up, stand-by
Traction request
79
FF4F
79
PUMP INC START
Pump motor is stopped
Start-up, stand-by,
running
Pump request
79
FFBD
189
FORW + BACK
Traction is stopped
Start-up, stand-by,
running
Traction request
80
FF50
80
SPEED FB. ERROR
MC is opened , EB is applied,
EVP stopped
Running
Valves or
Traction/Pump
request
81
FFAF
175
ENCODER ERROR XX
MC is opened, EB is applied,
Traction/Pump, valves stopped
Running
Valves or
Traction/Pump
request
153
FF52
153
WRONG ENC SET
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up
Key re-cycle
83
FF51
181
POS. EB. SHORTED
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up
Key re-cycle
84
3223
195
VACC OUT RANGE
Traction/Pump motor is stopped
Start-up, Stand-by,
Running
Traction/Pump
request
85
FFE2
226
PEDAL WIRE KO
Traction is stopped
Start-up, Stand-by,
Running
Traction request
86
FF56
86
VDC OFF SHORTED
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up, Stand-by,
Running
Key re-cycle
88
FFC8
200
POWERMOS SHORTED
MC is opened, EB is applied,
traction/pump stopped
Start-up
Key re-cycle
89
FFE9
233
WRONG SLAVE VER.
MC opened, EB is applied,
Traction/Pump, valves stopped
Start-up
Key re-cycle
91
FFC5
197
CURRENT GAIN
Controller works, but with low
maximum current
Start-up, stand-by
92
6302
236
PARAM TRANSFER
MC stays closed, EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by,
running
Key re-cycle
93
FFC7
199
