TESTER (Master µC)
Parameter
Unit of measure
(resolution)
Description
IQIMAX LIM. TRA
(A)
Ampere (1 A)
Maximum value of the q-axis current component,
according to traction-related settings, expressed in
root-mean-square Ampere
IQIMAX LIM. BRK
(A)
Ampere (1 A)
Maximum value of the q-axis current component,
according to braking-related settings, expressed in
root-mean-square Ampere.
MOT. POWER WATT
(A)
Watt (1 W)
Estimation of the power supplied to the motor.
STATOR FLUX MWB
(A)
10
-3
Weber (0.1 mWb)
Estimation of the motor magnetic flux.
MOTION TORQUE NM
(A)
Nm (0.1 Nm)
Estimation of the motor torque.
STEER ANGLE
(A)
Degrees (1°)
Current steering- wheel angle. When the steering is
straight ahead STEER ANGLE is zero.
TEMPERATURE
(A)
Celsius degrees (1 °C)
Temperature measured on the inverter base plate.
This temperature is used for the HIGH TEMPERATURE
alarm.
TEMPERATURE SLV
(A)
Celsius degrees (1 °C)
Temperature measured on the inverter base plate.
This temperature is used for the HIGH TEMPERATURE
alarm.
MOTOR TEMPERAT.
(A)
Celsius degrees (1 °C)
Motor-windings temperature.
Normally the sensor is a PTC Philips KTY84-130. This
temperature is used for the MOTOR OVERTEMP alarm.
DI2-A8 SEAT SW
(D, C)
OFF/ON
Status of the TILLER/SEAT input A8 (A6).
DI3-A13 QI/PB SW
(D, C)
OFF/ON
Status of the quick-inversion/pedal-brake input A17 (A11).
DI0-A6 FW SW
(D, C)
OFF/ON
Status of the forward-request input A6 (A4).
DI1-A7 BW SW
(D, C)
OFF/ON
Status of the backward-request input A7 (A5).
DI0-A6 ENABLE
(D, C)
OFF/ON
Status of the lowering-request input A6 (A4).
DI7-A2 SR/HB
(D, C)
OFF/ON
Status of the speed-reduction/hand-brake input A2.
