Zapi DUALACE2 NEW GENERATION User Manual

AFNZPxxx– DUALACE2 NEW GENERATION – User Manual Page 99/169
TESTER (Master µC)
Parameter
Unit of measure
(resolution)
Description
DI6-A1 SPARE
(D)
OFF/ON
Status of the spare input A1.
DI4-A11 LIFT
(D, C)
OFF/ON
Status of the lift-request input A11 .
DI5-A12 LOWER
(D, C)
OFF/ON
Status of the lowering-request input A12.
DI6-A1 SPD1 SW
(C)
OFF/ON
Status of the speed1 input A1.
IN0 BUMPER STOP
(CO)
OFF/ON
Status of the bumper stop input 0.
IN1 BUMPER STOP
(CO)
OFF/ON
Status of the bumper stop input 1.
A5 POT#1
(D, CO)
Volt (0.01 V)
Voltage of the analog input 1 A5 (A3).
A16 POT#2
(D, CO)
Volt (0.01 V)
Voltage of the analog input 2 A16 (A10).
A14 POT#3
(D, CO)
Volt (0.01 V)
Voltage of the analog signal on A14.
A22 POT#4
(D, CO)
Volt (0.01 V)
Voltage of the analog signal on A22.
A34 POT#5
(D, CO)
Volt (0.01 V)
Voltage of the analog signal on A34.
A35 POT#6
(D, CO)
Volt (0.01 V)
Voltage of the analog signal on A35.
MAIN CONT.
(D, CO)
% (1%)
Voltage applied over the main contactor coil. It
corresponds to the duty cycle value of PWM applied,
expressed as percentage.
ELEC.BRAKE MST
(D, CO)
% (1%)
Voltage applied over the electromechanical brake coil. It
corresponds to the duty cycle value of PWM applied,
expressed as percentage.
ELEC.BRAKE SLV
(D, D.CO)
% (1%)
Voltage applied over the electromechanical brake coil. It
corresponds to the duty cycle value of PWM applied,
expressed as percentage.
SET EVP
(D, CO)
% (1%)
Setpoint of proportional electrovalve EVP.
