Zebra DS8178 Product Reference Guide

6 - 8 DS8178 Digital Scanner Product Reference Guide
Snapshot Mode Timeout
Parameter # 323 (SSI # F0h 43h)
This parameter sets the amount of time the digital scanner remains in Snapshot Mode. The digital scanner exits
Snapshot Mode when you pull the trigger, or when the Snapshot Mode Timeout elapses. To set this timeout value,
scan the Set Snapshot Mode Timeout bar code below followed by a bar code from Appendix G, Numeric Bar
Codes. The default value is 0 which represents 30 seconds; values increment by 30. For example, 1 = 60 seconds,
2 = 90 seconds, etc.
To quickly re-set the default timeout to 30 seconds, scan the 30 Seconds bar code below.
If you select No Timeout, the digital scanner remains in Snapshot Mode until you pull the trigger.
Set Snapshot Mode Timeout
*30 Seconds
No Timeout

Zebra DS8178 Specifications

General

Product color	Black
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Photo diode
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Optical sensor resolution	1280 pixels
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
PC connection	RS-232/USB
Wireless range	100 m
Bluetooth version	4.0
Standard interfaces	USB, RS-232, Bluetooth
Connectivity technology	Wired & Wireless
Battery life	83 h
Battery capacity	2500 mAh
Power source type	Battery

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	235.3 g
