12 - 38 DS8178 Digital Scanner Product Reference Guide

Code 39 Reduced Quiet Zone

Parameter # 1209 (SSI # F8h 04h B9h)

Scan one of the following bar codes to enable or disable decoding Code 39 bar codes with reduced quiet zones. If

you select Enable, select a 1D Quiet Zone Level on page 12-86.

Code 93

Enable/Disable Code 93

Parameter # 9 (SSI # 09h)

To enable or disable Code 93, scan the appropriate bar code below.

Enable Code 39 Reduced Quiet Zone

(1)

*Disable Code 39 Reduced Quiet Zone

(0)

*Enable Code 93

(1)

Disable Code 93

(0)
