12 - 84 DS8178 Digital Scanner Product Reference Guide

Redundancy Level 4

The following code types must be successfully read three times before being decoded:

Table 12-5 Redundancy Level 4 Codes

Code Type Code Length

All All

*Redundancy Level 1

(1)

Redundancy Level 2

(2)

Redundancy Level 3

(3)

Redundancy Level 4

(4)
