RS-232 Interface 9 - 15

Host Serial Response Time-out

This parameter specifies how long the digital scanner waits for an ACK, NAK, or CTS before determining that a

transmission error occurred. This only applies when in one of the ACK/NAK software handshaking modes, or

RTS/CTS hardware handshaking mode.

* Minimum: 2 sec

Low: 2.5 sec

Medium: 5 sec

High: 7.5 sec

Maximum: 9.9 sec
