RS-232 Interface 9 - 17

Intercharacter Delay

This parameter specifies the intercharacter delay inserted between character transmissions.

* Minimum: 0 msec

Low: 25 msec

Medium: 50 msec

High: 75 msec

Maximum: 99 msec
