12 - 24 DS8178 Digital Scanner Product Reference Guide

ISSN EAN

Parameter # 617 (SSI # F1h 69h)

To enable or disable ISSN EAN, scan the appropriate bar code below.

Code 128

Enable/Disable Code 128

Parameter # 8 (SSI # 08h)

To enable or disable Code 128, scan the appropriate bar code below.

Enable ISSN EAN

(1)

*Disable ISSN EAN

(0)

*Enable Code 128

(1)

Disable Code 128

(0)
