12 - 82 DS8178 Digital Scanner Product Reference Guide

UPU FICS Postal

Parameter # 611 (SSI # F1h 63h)

To enable or disable UPU FICS Postal, scan the appropriate bar code below.

Mailmark

Parameter # 1337 (SSI # F8h 05h 39h)

To enable or disable Mailmark, scan the appropriate bar code below.

Enable UPU FICS Postal

(1)

*Disable UPU FICS Postal

(0)

*Disable Mailmark

(0)

Enable Mailmark

(1)
