Zebra DS8178 Product Reference Guide

Symbologies 12 - 3
UPC-A Preamble 34 22h System Character 12-18
UPC-E Preamble 35 23h System Character 12-18
UPC-E1 Preamble 36 24h System Character 12-20
Convert UPC-E to A 37 25h Disable 12-21
Convert UPC-E1 to A 38 26h Disable 12-21
EAN-8/JAN-8 Extend 39 27h Disable 12-22
Bookland ISBN Format 576 F1h 40h ISBN-10 12-22
UCC Coupon Extended Code 85 55h Disable 12-23
Coupon Report 730 F1h DAh New Coupon
Format
12-23
ISSN EAN 617 F1h 69h Disable 12-24
Code 128
Code 128 8 08h Enable 12-24
Set Length(s) for Code 128 209, 210 D1h, D2h Any Length 12-25
GS1-128 (formerly UCC/EAN-128) 14 0Eh Enable 12-27
ISBT 128 84 54h Enable 12-27
ISBT Concatenation 577 F1h 41h Autodiscriminate 12-28
Check ISBT Table 578 F1h 42h Enable 12-29
ISBT Concatenation Redundancy 223 DFh 10 12-29
Code 128 Security Level 751 F1h EFh Security Level 1 12-30
Code 128 Reduced Quiet Zone 1208 F8h 04h B8h Disable 12-31
Ignore Code 128 <FNC4> 1254 F8h 04h E6h Disable 12-31
Code 39
Code 39 0 00h Enable 12-32
Trioptic Code 39 13 0Dh Disable 12-32
Convert Code 39 to Code 32
(Italian Pharmacy Code)
86 56h Disable 12-33
Code 32 Prefix 231 E7h Disable 12-33
Set Length(s) for Code 39 18, 19 12h, 13h 1 to 55 12-34
Code 39 Check Digit Verification 48 30h Disable 12-35
Transmit Code 39 Check Digit 43 2Bh Disable 12-35
Table 12-1 Symbology Parameter Defaults (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number

Zebra DS8178 Specifications

General

Product color	Black
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Photo diode
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Optical sensor resolution	1280 pixels
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
PC connection	RS-232/USB
Wireless range	100 m
Bluetooth version	4.0
Standard interfaces	USB, RS-232, Bluetooth
Connectivity technology	Wired & Wireless
Battery life	83 h
Battery capacity	2500 mAh
Power source type	Battery

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	235.3 g
