12 - 44 DS8178 Digital Scanner Product Reference Guide

Set Lengths for Interleaved 2 of 5 (continued)

I 2 of 5 - One Discrete Length

I 2 of 5 - Two Discrete Lengths

*I 2 of 5 - Length Within Range

I 2 of 5 - Any Length
