Zebra DS8178 Product Reference Guide

A - 10 DS8178 Digital Scanner Product Reference Guide
Code 128 Reduced Quiet Zone 1208 F8h 04h B8h Disable 12-31
Ignore Code 128 <FNC4> 1254 F8h 04h E6h Disable 12-31
Code 39
Code 39 0 00h Enable 12-32
Trioptic Code 39 13 0Dh Disable 12-32
Convert Code 39 to Code 32 (Italian
Pharmacy Code)
86 56h Disable 12-33
Code 32 Prefix 231 E7h Disable 12-33
Set Length(s) for Code 39 18, 19 12h, 13h 1 to 55 12-34
Code 39 Check Digit Verification 48 30h Disable 12-35
Transmit Code 39 Check Digit 43 2Bh Disable 12-35
Code 39 Full ASCII Conversion 17 11h Disable 12-36
Code 39 Security Level 750 F1h EEh Security Level 1 12-37
Code 39 Reduced Quiet Zone 1209 F8h 04h B9h Disable 12-38
Code 93
Code 93 9 09h Enable 12-38
Set Length(s) for Code 93 26, 27 1Ah, 1Bh 1 to 55 12-39
Code 11
Code 11 10 0Ah Disable 12-40
Set Lengths for Code 11 28, 29 1Ch, 1Dh 4 to 55 12-40
Code 11 Check Digit Verification 52 34h Disable 12-42
Transmit Code 11 Check Digit(s) 47 2Fh Disable 12-42
Interleaved 2 of 5 (ITF)
Interleaved 2 of 5 (ITF) 6 06h Enable 12-43
Set Lengths for I 2 of 5 22, 23 16h, 17h 6 to 55 12-43
I 2 of 5 Check Digit Verification 49 31h Disable 12-45
Transmit I 2 of 5 Check Digit 44 2Ch Disable 12-45
Convert I 2 of 5 to EAN 13 82 52h Disable 12-46
I 2 of 5 Security Level 1121 F8h 04h 61h Security Level 1 12-46
Table A-1 Parameter Defaults (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number

Zebra DS8178 Specifications

General

Product color	Black
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Photo diode
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Optical sensor resolution	1280 pixels
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
PC connection	RS-232/USB
Wireless range	100 m
Bluetooth version	4.0
Standard interfaces	USB, RS-232, Bluetooth
Connectivity technology	Wired & Wireless
Battery life	83 h
Battery capacity	2500 mAh
Power source type	Battery

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	235.3 g
