B - 12 DS8178 Digital Scanner Product Reference Guide

Country Codes (Continued)

Portuguese (Brazilian ABNT)

Portuguese (Brazilian ABNT2)

Portuguese (Portugal)

Romanian

(Windows XP)

Romanian (Legacy)

(Win 7 or higher)

Romanian (Standard)

(Win 7 or higher)
