Maintenance, Troubleshooting, and Technical Specifications 3 - 11
Drop Specification (Scanner) Designed to withstand multiple drops at 6.0 ft./1.8 m to concrete
Tumble Specification (Scanner) Designed to withstand 2,000 tumbles in 1.5 ft./0.5 m tumbler
Note: 1 tumble = 0.5 cycle
Ambient Light Immunity 0 to 9000 Foot Candles/0 to 96,840 Lux
Environmental Sealing Scanner rated IP42
Electrostatic Discharge (ESD) - Scanner,
Presentation Cradle, Desk/Wall Cradle
+/-15kV Air, +/-8kV Indirect, +/-8kV Direct
Wireless Connectivity
Bluetooth Radio Standard Bluetooth Version 4.0 with BLE: Class 1 330 ft. (100m)
and Class 2 33 ft. (10m), Serial Port and HID Profiles
Adjustable Bluetooth Power Class 1: Output power adjustable down from 4 dBm in 8 Steps
Class 2: Output power adjustable down from 2 dBm in 8 Steps
Battery (@ 25°C)
Battery Capacity / Battery Type 2500mAH Li-ion
Battery Management Type PowerPrecision+ Smart Battery
Scans Per Battery Charge (1 scan/sec) 65,000
Operating Time Per Charge
Note: 10 scans in 10 seconds with a 50
second rest.
83 hours
Typical Charge Time From Empty To Full
Standard USB
BC1.2 USB
External 5V Source
External 12V Source
CR8178-SC CR8178-PC
7 hrs 45 min 9 hrs 15 min
3 hrs 3 hrs 15 min
4 hrs 30 min 5 hrs
2 hrs 15 min 2 hrs 15 min
Accessories
Desk/Wall Cradle CR8178-SC
Presentation Cradle CR8178-PC
Document Capture Stand
p/n STND-DC0081W-04
For use with the DS8178-SR/DL in the presentation cradle
(CR8178-PC)
Spare Battery BTRY-DS81EAB0E-00 (Worldwide)
BTRY-DS81EAB0E-00K (India & S. Korea)
Table 3-2 Technical Specifications (Continued)
Item Description
