Zebra DS8178

To Next Page

To Previous Page

4 - 32 DS8178 Digital Scanner Product Reference Guide

Connection Maintenance Interval (continued)

Set Interval to 2 Hours

(3)

Set Interval to 4 Hours

(4)

Set Interval to 8 Hours

(5)

Set Interval to 24 Hours

(6)

Set Interval to Forever

(7)
