4: Troubleshooting
Troubleshooting Procedures
P1061942-001 Zebra ZXP Series 1 Card Printer Service Manual 95
Example • Non-printing horizontal lines (white)
There are non-printing horizontal lines (white) on the card surfaces.
Possible Cause:
• Ribbon cartridge is not correctly positioned.
Solutions:
• Ensure that the ribbon is properly rolled onto the ribbon cores of the cartridge and that
there are no wrinkles in the ribbon.
• Replace ribbon cartridge. Refer to Section 2.1: Installing the Ribbon Cartridge.
Possible Cause:
• Printhead is dirty.
Solutions:
• Clean the Printhead. Refer to Section 6.2: Cleaning the Printhead.
Possible Cause:
• Printhead elements are damaged (e.g., scratched or burnt).
Solutions:
• Call Zebra Customer Service for Printhead replacement information; see Appendix I.
