150 Zebra ZXP Series 1 Card Printer Service Manual P1061942-001
5: Replacement Procedures
Procedures
Replacement
Install the Gear and Lower Pulley (arrows below).
Important • When installing the Gear, ensure that the grooves (outlined in orange below) are
aligned as indicated.
