Zebra ZXP 1 Series User Manual

216 Zebra ZXP Series 1 Card Printer Service Manual P1061942-001
D: CardSense Single Card Feed Option
Setting Up the Printer Driver
Card Setup tab allows the user to set the single-card feed mode.
To access the Card Setup tab, select Start > Devices and Printers. Right click on the Zebra
ZXP Card Printer listing, then select Printing preferences > Card Setup.
Step 1. Make the appropriate Single Feed option selection from the Current Status
dropdown menu:
• Card feeder: The printer will attempt to a pull a card from the Card Feeder.
If the Card Feeder is empty, the printer will generate an
OUT OF CARDS
error message.
• Single feeder slot: For each print job, the printer will generate an
INSERT
CARD
message. Any cards in the Card Feeder will not be used.
• Auto feed: The printer will attempt to feed cards from Card Feeder first. If
Card Feeder is empty, the printer will generate an
INSERT CARD message.
No
OUT OF CARDS error message will be generated.
Step 2. Click the Apply button, then click the OK button.
Important • You do not have to remove the components of the Single-Card Feed Kit in order
to operate in normal mode (printing cards from the Card Feeder).

Zebra ZXP 1 Series Specifications

General

Resolution	300 dpi
Connectivity	USB 2.0
Power Requirements	100-240 VAC, 50-60 Hz
Print Technology	Dye sublimation
Card Capacity	100 cards (input hopper)
Card Size	CR-80 ISO 7810
Dimensions	368 mm (D)
Memory	32 MB
Operating Temperature	15°C to 30°C
Operating Humidity	20% to 65% non-condensing
Card Thickness	0.3mm - 1.06mm
