242 Zebra ZXP Series 1 Card Printer Service Manual P1061942-001
G: Upgrade Kit Instructions
Step 6. Turn the Printer over.
Step 7. Raise the Printer Lid.
Step 8. Place the black Cleaner Roller into the tabs (circled below) at the front of the printer.
Step 9. While holding the black Cleaner Roller down
FIRMLY, turn the printer ON. The
printer will initialize, raise the blue tabs, and snap the roller into place.
Step 10. Install the Cleaning Cartridge Housing, and open the lid. An alignment tab is located
on the left side of the Cleaning Cartridge Housing to ensure proper installation.

Zebra ZXP 1 Series Specifications

General

Resolution	300 dpi
Connectivity	USB 2.0
Power Requirements	100-240 VAC, 50-60 Hz
Print Technology	Dye sublimation
Card Capacity	100 cards (input hopper)
Card Size	CR-80 ISO 7810
Dimensions	368 mm (D)
Memory	32 MB
Operating Temperature	15°C to 30°C
Operating Humidity	20% to 65% non-condensing
Card Thickness	0.3mm - 1.06mm
