REQUIRED PARTS AND TOOLS
Page 10
• Watertight cable grip for the cable entrance on the Processor
• Control Head Dimensions Variations & Installation Sheets
3.3
ELECTRIC CABLE
Eight-Conductor Cable (Control Head to Control Processor)
Shielded 20 AWG, 300V, PVC Insulated: -20 degrees C to +80 degrees C.
UL VW-1 PVC Jacket. Color Coded.
Two Conductor Power Cable (Processor to DC Power Supply)
14 AWG, 300V, PVC Insulated: -20 degrees C to +105 degrees C
UL VW-1 PVC Jacket. Red with purple stripe and black.
Two Conductor Start Interlock Cable (Starter Switch to Processor to Starter Sole-
noid)
16 AWG, 300 V, PVC Insulated: -20 degrees C to +105 degrees C
UL VW-1 PVC Jacket. Yellow with red stripe.
3.4 TOOLS REQUIRED FOR INSTALLATION
• Wago Tool (provided)
• Anti-static Wrist Strap (provided)
• Wire cutter, stripper, and crimper
(Recommend Thomas & Betts WT-2000)
• Screwdriver – med. Phillips #2
• Screwdriver – med. straight slot
• Screwdriver -- small straight slot
• Hole saw -- 1 inch (25,4mm)
• Drills -- 9/32 inch (7,2mm) and 7/32 inch (5,6mm)
•Saw (appropriate type of saw for cutting material Control Head will be mounted on)
• Multi meter
NOTE: Retrofit applications may require planning for an adapter pad to cover the old Control
Head cutout. A variety of adapter and cover pads are available from ZF Mathers, LLC.
