Deck Mount or Exposed Mount
Ideal for outside Weather Mount
To prevent internal condensation and moisture build up the mount is drilled to allow air
circulation.
Part No. 12110
400 Series Watertight Enclosure
Gasket
10241
Control Head
Mounting
Holes
Watertight
Enclosure
.75 inch Diameter Hole
Locate where required.
(
two if Dual Control Head
)
3.54
(89,9mm)
4.72
(119,9mm)
6.29
(159,8mm)
Watertight
Cable Grip
(
two if Dual Control Head
)
Single or Dual
Control Head
