ZF Marine ClearCommand User Manual

Appendix A 6/20/01
Page 1
PARTS LIST
PART NO. DESCRIPTION
CONTROL HEADS
SINGLE SCREW
450-3L or 3R Left or Right Control Head, 'T' Lever
453-3L or 3R Left or Right Control Head, Chrome Knob Lever
455-3L or 3R Left or Right Control Head, Black Low Profile Lever
456-3L or 3R Left or Right Control Head, Chrome Low Profile Lever
750-L or –R Left or Right Control Head, Heavy Duty
TWIN SCREW (Synchronization Indication)
460-4 Control Head, 'T' Lever
463-4 Control Head, Chrome Knob Lever
464-4 Control Heads, Split, with Single Levers, Chrome Knobs (pair)
465-4 Control Head, Black Low Profile Lever
466-4 Control Head, Chrome Low Profile Lever
760 Control Head, Heavy Duty
MC2000-1 Black Head, Black Levers
MC2000-2 Chrome Head, Chrome Levers
MC2000-3 Gold Head, Gold Levers
MC2000-4 Black Head, Chrome Levers
MC2000-5 Black Head, Gold Levers
CABLE (Electric)
180 8-Cond. Shielded Cable Per/ft.
350 8-Cond. Shielded Cable 500' Spool
11811 8-Cond. Shielded Cable 1000’ Spool
212 2-Cond. Power Cable Per/ft.
349 2-Cond. Power Cable 250' Spool
183 2-Cond. Start Interlock Cable Per/ft.
355 2-Cond. Start Interlock Cable 250' Spool
13062-# 2-Cond. Start Interlock Cable [Cummins Connector] 10 ft/20 ft
(replace # with the length of harness required)
WIRE HARNESS (Plug)
Replace the # after the Part Number with the length of harness required. EXAMPLE: 13316-10;
13316-20; 13316-30
13316-# Serial Communication (Twin Screw)
13408-# Serial Communication (Multiple Screw)
13432-# Throttle, Voltage
13565-# Throttle, Voltage (Cummins Plug)
14148-# Throttle, Voltage (John Deere Plug)
13494-# Throttle, Current
13533-# Throttle, PWM
13239-# Magnetic Pickup or Pulse Transmitter
13322-# Clutch – Ahead/Astern/Clutch Power
13324-# Clutch – Ahead/Astern/Neutral/Clutch Power
13240-# Clutch – Ahead/Astern/Troll/Clutch Power
14152-# 2 Speed
13422-# ZF Autotroll
13676-# ZF Autotroll/MTU
13631-# Power/Start Interlock/Clutch Pressure/Alarm Circuit
13552-# Power/Start Interlock/Clutch Pressure
13756-# Power/Start Interlock
14134-# ZF CPP Junction Box Cable
14155-# CPP (Sol pwr, Ahd & Ast Sol, CPP PS, Clutch PS, Comb Mode)
14212-# CPP (Sol pwr, Ahd & Ast Sol, CPP PS)
