ZF Marine ClearCommand User Manual

REQUIRED PARTS AND TOOLS
Page 12
3.7 ENGINE STOP SWITCH
It is mandatory for an Engine Stop Switch to be located at each Sta-
tion.
3.8
CONTROL SYSTEM POWER
The Processor requires:
• A battery source of 12 or 24 volts DC
• A 10 ampere circuit breaker with manual reset
• Automatic Power Selector (refer to Appendix A - S-214 APS Ser-
vice Sheet)
The power for the Control System should come from the same power
distribution panel as the other required engine functions. (Refer to
Appendix C Drawing Notes)
WARNING: An Engine Stop Switch at each Station is an absolute requirement. Refer to CFR46,
SEC. 62.35-5 and ABYC P-24.5.8.

ZF Marine ClearCommand Specifications

General

Brand	ZF Marine
Model	ClearCommand
Category	Controller
Language	English
