ZF Mathers, LLC
1415 Pacific Drive
Burlington WA 98233-3103 U.S.A.
800-546-5455 / 360-757-6265
Fax: 360-757-2500
F-226 Rev.A 11/00
Vessel Name:_____________________________________ Trial Date:__________________ SSN:_____________
Owners Name:________________________________________________________________________________
Address:_________________________________________________________________________________
Tel/Fax/e-mail:_______________________________________________________________________________
Contact Name:_______________________________________________________________________________
APPLICATION:
A:Boat Builder________________________ Model_____________________ Size_________ Year_____
Original Equipment ___ Retrofit ___ Type of Controls Replaced_______________________________
B:Single or Twin Screw_________________________________________________________________
Engine Make__________________________ Model__________________________________________
Horsepower _______________ RPM______________ Engine Hours_____________________________
Reduction Gear/Drive______________________________ Model/Ratio_______ Trolling? Yes___ No___
Type of Service (Pleasure, Fishing, Rental, Etc.)______________________________________________
C:Number of Remote Stations___________________________________________________________
Actuator/Control Processor: Port Model_______________________ Starboard Model_____________________
Port SN:___________________ Starboard SN:_______________________
Before Running Engine:
Port Stbd
1. Voltage at the Battery Terminals. ________VDC ________VDC
2. Voltage at the Actuator/Control Processor. ________VDC ________VDC
3. Warm-up Indicator Light blinks in ’Ahead’. All Stations. Yes ___ No___ Yes___ No___
4. Electric Cables are supported every 18 inches (45,72cm) Yes ___ No___ Yes___ No___
5. Cable connections are tight at the Actuator/Control Processor and Control Heads.
Yes ___ No___ Yes___ No___
6. Engine Stop Switches at EACH
Remote Station are operational.
Yes ___ No___ Yes___ No___
7. Check push-pull cable match. Disconnect push-pull cables at the clutch and throttle. Check that cables travel in the correct
direction. Check the cable movement, insure that it matches clutch and throttle. Yes ___ No___ Yes___ No___
Dock Side Tests (Running):
1. Voltage at the Battery Terminals. ________VDC ________VDC
2. Does Engine ’Start’ when Controls are OFF? Yes ___ No___ Yes___ No___
3. Low Idle RPM. ________RPM ________RPM
4. High Idle RPM (optional). ________RPM ________RPM
5. Check Warm-Up Mode. Yes ___ No___ Yes___ No___
6. Check shift in both directions. Yes ___ No___ Yes___ No___
Sea Trial Report
