131
Setting up and aligning
3.2.1 Assembling stand
Attach two casters (one with and one
without a brake) to each end of the
stand.
Abb. 12: Attaching casters
Fasten two of the side struts, with the
broader ange at the bottom, to one
end of the stand with the screws and
associated washers, making them hand
tight.
Abb. 13: Assembling stand
Loosely attach the other end of the
stand to the pre-assembled side struts.
Abb. 14: Assembling stand
Insert the shelf between the two
bottom side struts of the stand.
Loosely attach the other two side
struts in the envisaged positions on
the opposite side of the stand with the
screws and associated washers.
Abb. 15: Assembling stand
