Changing modes
6. Changing modes
This part of the operator’s guide refers exclusively to machines with tubular
system functionality.
6.1 Tabletop embroidery - tubular system
The conversion is not to be carried out when the machine is
running.
Abb. 35: Examples for SPRINT
(1) Tabletop embroidery
(2) Tubular system embroidery
6.1.1 Dismantling frame locator
Take out single frame (1).
Slacken o screws (2).
Remove Z rail (3).
Abb. 36: Dismantling frame locator
1
2
1
2
3
