ZSK JAFA - Operation and Controls

141
Machine overview
5.2 Operation
This chapter provides an overview of the embroidery machine’s operating
elements. These controls are used, for example, to position the pantograph, for
starting and stopping the embroidering routine, for reverse embroidering, and
when working with appliqués.
The position of the individual operating elements on the machine is
illustrated under Machine overview and Control unit.
5.2.1 Main switch
The machine and control cabinet are switched on and o with the main switch.
5.2.2 EMERGENCY STOP
The main switch also serves as the EMERGENCY STOP switch.
Before switching the machine back on, make sure that the cause of
the EMERGENCY STOP has been rectied.
All the operating elements described below operate only if the main
switch is switched on.
