Unloading, unpacking, handling
Slacken o the bolts securing the wooden transit blocks to the bottom of the crate.
See (Abb. 52).
(1) Fixing bolts
(2) Floor of pallet/crate
(3) Transit block
Abb. 52: Machine mounted on wooden transit blocks, illustration
9.3.2 If delivered on a pallet
Unloading and handling instructions are attached to the foil packaging.
Proceed as follows to unpack a machine delivered on a pallet:
Remove the foil packaging
Remove the desiccant sachets.
Remove all individually packed components situated on and underneath the work
table.
Slacken o the xing bolts securing the wooden transit blocks to the pallet. See
(Abb. 52).
Machines without casters
Do not detach the machine from the transit blocks until you
install it in the working position. They are not replaced by the
machine shoes until the machine is nally installed.
