Operating elements
This chapter provides an overview of the embroidery machine’s operating
elements. These controls are used, for example, to switch the machine on and o,
to position the pantograph, for starting and stopping the embroidering routine, for
reverse embroidering, and when working with appliqués.
The position of the individual operating elements on the machine is
illustrated under General view and Control unit.
12.2 Main switch
The machine and control unit are switched on and o with the main switch.
12.2.1 1 and 2-head machines
The main switch of the 1 and 2-head machines also functions as the
EMERGENCY STOP switch.
12.2.2 4 to 8-head machines
4 to 8-head machines are equipped with additional, separate EMERGENCY
STOP buttons.
12.3 EMERGENCY STOP
The main switch also functions as an EMERGENCY STOP switch on 1 and
2-head machines; machines with a larger number of heads have EMERGENCY
STOP buttons.
