147
Machine overview
Aligning by way of control unit
Aligning the pantograph by way of the control unit is possible only in
the Machine module.
By way of the control unit the pantograph position can also be controlled with
reference to the screen display. This allows paths to be traveled quickly or slowly
or in 1 mm or 1/10 mm steps (increments).
Press the Taste [U5] button below the screen display to activate manual
pantograph positioning.
Ö The following symbols are dis-
played at the bottom of the screen.
The control unit operator’s guide contains more detailed information
on using the menu keys.
Press button [U1] and hold down arrow button to move pantograph continuously
and fast.
Press button [U2] and hold down arrow button to move pantograph continuously
and slowly.
Press button [U3] and briey press arrow button to move pantograph in 1 mm
steps with each press.
Press button [U4] and briey press arrow button to move pantograph in 1/10 mm
steps with each press.
Once you have aligned the pantograph, switch o the manual
pantograph positioning function. With manual pantograph position-
ing selected, the machine cannot be started.
