132
Setting up and aligning
Insert the variable-height machine rests
into the ends of the stand from above.
With the rests located at the desired
height, fasten the screws with washers
so that they are hand tight.
Abb. 16: Assembling stand
Place the stand on a rm, at surface.
Tighten all the screws.
3.2.2 Installing machine
The machine is to be lifted only by 4 persons, each of whom can
lift at least 25 kg.
Lift the machine by the 4 carrying
handles.
Abb. 17: Installing machine
