Parameters 125
10.12 DI4 OFF delay Defines the deactivation delay for digital output DI4. See
parameter 10.05 DI1 ON delay.
0.0 -
0.0 3000.0 s Deactivation delay for DI4. 10 = 1 -
10.13 DI5 ON delay Defines the activation delay for digital output DI5. See
parameter 10.05 DI1 ON delay.
0.0 -
0.0 3000.0 s Activation delay for DI5. 10 = 1 -
10.14 DI5 OFF delay Defines the deactivation delay for digital output DI5. See
parameter 10.05 DI1 ON delay.
0.0 -
0.0 3000.0 s Deactivation delay for DI5. 10 = 1 -
10.21 RO status Status of relay outputs RO1. -
0000h…FFFFh Status of relay outputs. 1 = 1
10.22 RO force selection Selects the relay outputs that will be controlled by
parameter 10.23. The signals connected to the relay
outputs can be overridden for eg. testing purposes. A bit in
parameter 10.23 RO forced data is provided for each relay
output, and its value is applied whenever the
corresponding bit in this parameter is 1.
Note: Boot and power cycle reset the force selections
(parameters 10.22 and 10.23).
0000h
0000h…FFFFh Override selection for relay outputs. 1 = 1
10.23 RO forced data Contains the values of relay outputs that are used instead
of the connected signals if selected in parameter 10.22
RO force selection. Bit 0 is the forced value for RO1.
This provides the possibility to test the drive functionality
without the plant wiring. Ton and Toff delays are passed.
0000h…FFFFh Forced RO values. 1 = 1
10.24 RO1 source Selects a drive signal to be connected to relay output
RO1.
Fault (-1)
Not energized Output is not energized. 0
Energized Output is energized. 1
Ready run Bit 1 of 06.11 Main status word. 2
Enabled Bit 0 of 06.16 Drive status word 1.4
No. Name/Value Description Default
FbEq 16
Bit Value
0 1 = RO1 is energized.
1...15 Reserved.
Bit Value
0 1 = Force RO1 to value of bit 0 of parameter 10.23 RO forced data (0 = Normal mode).
1…15 Reserved
Bit Value
0 Forced value (0 or 1) for parameter 10.22 RO force selection.
1…15 Reserved
ACS180 FW.book Page 125 Tuesday, March 9, 2021 2:25 PM
