Parameters 129
Overvoltage A drive is tripped to overvoltage fault. 18
Drive temp A drive is tripped to drive temperature fault. 19
Undervoltage A drive is tripped to undervoltage fault. 20
Motor temp A drive is tripped to motor temperature fault. 21
Brake command Bit 0 of 44.01 Brake control status. 22
Ext2 active Bit 11 of 06.16 Drive status word 1.23
Remote control Bit 9 of 06.11 Main status word.24
Supervision 1 Bit 0 of 32.01 Supervision status.33
Supervision 2 Bit 1 of 32.01 Supervision status.34
Supervision 3 Bit 2 of 32.01 Supervision status.35
Start delay Bit 13 of 06.17 Drive status word 2.39
RO/DIO control word
bit0
Bit 0 of 10.99 RO/DIO control word.40
Event word 1 Parameter 04.40 Event word 1.53
User load curve Bit 3 (Outside load limit) of 37.01 ULC output status word
(see page 231).
61
RO/DIO control word Maps to corresponding bit in parameter 10.99 RO/DIO
control word. For example, Bit 0 of 10.99 RO/DIO control
word controls RO1, Bit 8 of 10.99 RO/DIO control word
controls DO1, and so on.
62
Other [bit] Source selection (see Terms and abbreviations). -
11.07 DO1 ON delay Defines the on (activation) delay for digital input/output
DO1 (when used as a digital output or digital input).
0.00 s
0.0 … 3000.0 s Activation delay for DO1. 10 = 1 s
11.08 DO1 OFF delay Defines the deactivation delay for digital input/output DO1
(when used as a digital output or digital input). See
parameter 11.07 DO1 ON delay.
0.00 s
0.0 … 3000.0 s Deactivation delay for DO1. 10 = 1 s
11.13 DI3 configuration Selects the type of digital input DI3: normal digital input or
frequency input.
Digital input
Digital input Digital input. See parameter 11.42 for more information. 0
Frequency input Frequency input. 1
11.17 DI4 configuration Selects the type of digital input DI4: normal digital input or
frequency input.
Digital input
Digital input Digital input. 0
Frequency input Frequency input. 1
11.21 DI5 configuration Selects the type of digital input DI5: normal digital input or
analog input.
Analog input
Digital input Digital input. 0
Analog input Analog input. 2
11.38 Freq in 1 actual value Displays the value of frequency input 1 before scaling.
See parameter 11.42 Freq in 1 min.
This parameter is read-only.
-
0 … 16000 Hz Unscaled value of frequency input 1. 1 = 1 Hz
No. Name/Value Description Default
FbEq 16
