278 Parameters
PID PID macro 14
96.05 Macro active Shows which control macro is currently selected. See
chapter Control macros for more information.
To change the macro, use parameter 96.04 Macro select.
ABB
standard
Done Macro selection complete; normal operation. 0
ABB standard ABB standard macro. For scalar motor control. 1
Hand/Auto Hand/Auto macro. 5
Hand/PID Hand/PID macro. 8
Modbus RTU Modbus RTU 9
Alternate Alternate macro 12
Motor potentiometer Motor potentiometer macro 13
PID PID macro 14
96.06 Parameter restore Restores the original settings of the control program, ie.
parameter default values.
Note: This parameter cannot be changed while the drive
is running.
Done
Done Restoring is completed. 0
Restore defaults All editable parameter values are restored to default
values, except
• motor data and ID run results
• end user texts, such as customized warnings and faults
(external faults and changed), and the drive name
• control panel/PC communication settings
• fieldbus adapter settings
• control macro selection and the parameter defaults
implemented by it
• parameter 95.20 HW options word 1 and the
differentiated defaults implemented by it.
• user lock configuration parameters 96.100…96.102.
8
Clear all All editable parameter values are restored to default
values, except
• end user texts, such as customized warnings and faults
(external faults and changed), and the drive name
• control panel/PC communication settings
• fieldbus adapter settings (clears entire existing
settings)
• control macro selection and the parameter defaults
implemented by it
• parameter 95.20 HW options word 1 and the
differentiated defaults implemented by it.
• user lock configuration parameters 96.100…96.102.
PC tool communication is interrupted during the restoring.
62
Reset all fieldbus
settings
Restores all fieldbus and communication related settings
to default values.
Note: Fieldbus, control panel and PC tool communication
are interrupted during the restore.
32
Reset home view Restores the Home view layout to show the values of the
default parameters defined by the control macro use.
512
No. Name/Value Description Default
FbEq 16
