280 Parameters
User3 backup User set 3 has been saved or loaded. 22
User4 backup User set 4 has been saved or loaded. 23
96.11 User set save/load Enables the saving and restoring of up to four custom sets
of parameter settings.
The set that was in use before powering down the drive is
in use after the next power-up.
Notes:
• Some hardware configuration settings, such as fieldbus
and encoder configuration parameters (groups 14…16,
47, 50…58 and 92…93) are not included in user
parameter sets.
• Parameter changes made after loading a set are not
automatically stored – they must be saved using this
parameter.
• This parameter cannot be changed while the drive is
running
No action
No action Load or save operation complete; normal operation. 0
User set I/O mode Load user parameter set using parameters 96.12 User set
I/O mode in1 and 96.13 User set I/O mode in2.
1
Load set 1 Load user parameter set 1. 2
Load set 2 Load user parameter set 2. 3
Load set 3 Load user parameter set 3. 4
Load set 4 Load user parameter set 4. 5
Save to set 1 Save user parameter set 1. 18
Save to set 2 Save user parameter set 2. 19
Save to set 3 Save user parameter set 3. 20
Save to set 4 Save user parameter set 4. 21
96.12 User set I/O mode in1 When parameter 96.11 User set save/load is set to User
set I/O mode, selects the user parameter set together with
parameter 96.13 User set I/O mode in2 as follows:
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
No. Name/Value Description Default
FbEq 16
Status of
source defined
by par. 96.12
Status of source
defined by par.
96.13
User parameter
set selected
00Set 1
10Set 2
01Set 3
11Set 4
