174 Actual signals and parameters
Bit 5 = SUPPLY PHASE
Bit 6 = Reserved
Bit 7 = OVERSPEED
Bit 8 = Reserved
Bit 9 = DRIVE ID
Bit 10 = CONFIG FILE
Bit 11 = SERIAL 1 ERR
Bit 12 = EFB CON FILE
Bit 13 = FORCE TRIP
Bit 14 = MOTOR PHASE
Bit 15 = OUTP WIRING
0307 FAULT WORD
3
A 16-bit data word. For the possible causes and remedies
and fieldbus equivalents, see chapter Fault tracing on page
311.
Bit 0 = EFB 1
Bit 1 = EFB 2
Bit 2 = EFB 3
Bit 3 = INCOMPATIBLE SW
Bit 4 = USER LOAD CURVE
Bit 5 = UNKNOWN EXTENSION
Bit 6 = INLET VERY LOW
Bit 7 = OUTLET VERY HIGH
Bit 8 = INLET LOW
Bit 9 = OUTLET HIGH
Bit 10…14 = System error
Bit 15 = Parameter setting fault
0308 ALARM WORD
1
A 16-bit data word. For the possible causes and remedies
and fieldbus equivalents, see chapter Fault tracing on page
311.
An alarm can be reset by resetting the whole alarm word:
Write zero to the word.
Bit 0 = OVERCURRENT
Bit 1 = OVERVOLTAGE
Bit 2 = UNDERVOLTAGE
Bit 3 = DIR LOCK
Bit 4 = IO COMM
Bit 5 = AI1 LOSS
Bit 6 = AI2 LOSS
Bit 7 = PANEL LOSS
Bit 8 = DEVICE OVERTEMP
Bit 9 = MOTOR TEMP
Bit 10 = Reserved
All actual signals
No. Name/Value Description FbEq
