Fault tracing 323
0031 EFB 1
(FF92)
0307 bit 0
Error from the
embedded fieldbus
(EFB) protocol
application. The
meaning is protocol
dependent.
See chapter Fieldbus control with the
embedded fieldbus on page 287.
0032 EFB 2
(FF93)
0307 bit 1
0033 EFB 3
(FF94)
0307 bit 2
0034 MOTOR PHASE
(FF56)
0306 bit 4
Motor circuit fault due
to missing motor
phase or motor
thermistor relay (used
in motor temperature
measurement) fault.
Check motor and motor cable.
Check motor thermistor relay (if used).
0035 OUTP WIRING
(FF95)
0306 bit 15
(programmable fault
function 3023)
Incorrect input power
and motor cable
connection (ie, input
power cable is
connected to drive
motor connection).
The fault can be
erroneously declared if
the drive is faulty or
the input power is a
delta grounded system
and the motor cable
capacitance is large.
Check input power connections.
0036 INCOMPATIBLE
SW
(630F)
0307 bit 3
Loaded software is not
compatible.
Contact your local ABB
representative.
0038 USER LOAD
CURVE
(FF6B)
0307 bit 4
Condition defined by
3701 USER LOAD C
MODE has been valid
longer than the time
set by 3703 USER
LOAD C TIME.
See parameter group 37 USER LOAD
CURVE.
0039 UNKNOWN
EXTENSION
(7086)
0307 bit 5
Option module not
supported by the drive
firmware is connected
to the drive.
Check connections.
0040 INLET VERY LOW
(8A81)
0307 bit 6
Pressure at pump/fan
inlet too low
Check for a closed valve on the inlet
side of the pump/fan.
Check piping for leaks.
See parameter group 44 PUMP
PROTECTION.
0041 OUTLET VERY
HIGH
(8A83)
0307 bit 7
Pressure at pump/fan
outlet too high
Check piping for blocks.
See parameter group 44 PUMP
PROTECTION.
CODE FAULT CAUSE WHAT TO DO
