324 Fault tracing
0042 INLET LOW
(8A80)
0307 bit 8
Pressure at pump/fan
inlet too low
Check for a closed valve on the inlet
side of the pump/fan.
Check piping for leaks.
See parameter group 44 PUMP
PROTECTION.
0043 OUTLET HIGH
(8A82)
0307 bit 9
Pressure at pump/fan
outlet too high
Check piping for blocks.
See parameter group 44 PUMP
PROTECTION.
0101 SERF CORRUPT
(FF55)
0307 bit 14
Drive internal error Write down fault code and contact
your local ABB representative.
0103 SERF MACRO
(FF55)
0307 bit 14
0201 DSP T1
OVERLOAD
(6100)
0307 bit 13
0202 DSP T2
OVERLOAD
(6100)
0307 bit 13
0203 DSP T3
OVERLOAD
(6100)
0307 bit 13
0204 DSP STACK
ERROR
(6100)
0307 bit 12
0206 CB ID ERROR
(5000)
0307 bit 11
1000 PAR HZRPM
(6320)
0307 bit 15
Incorrect frequency
limit parameter setting
Check parameter settings. Check that
following applies:
• 2007 MINIMUM FREQ <
2008 MAXIMUM FREQ
• 2007 MINIMUM FREQ / 9907
MOTOR NOM FREQ and 2008
MAXIMUM FREQ / 9907 MOTOR
NOM FREQ are within range.
1001 PAR PFC REF NEG
(6320)
0307 bit 15
Incorrect PFC
parameters
Check parameter group 81 PFC
CONTROL settings. Check that
following applies:
• 2007 MINIMUM FREQ > 0 when
8123
is AC
TIVE or SPFC ACTIVE.
CODE FAULT CAUSE WHAT TO DO
