224 Actual signals and parameters
3404 OUTPUT1 DSP
FORM
Defines the format for the displayed signal (selected by
parameter 3401 SIGNAL1 PARAM).
DIRECT
+/-0 Signed/Unsigned value. Unit is selected by parameter 3405
OUTPUT1 UNIT.
Example: PI (3.14159)
0
+/-0.0 1
+/-0.00 2
+/-0.000 3
+0 4
+0.0 5
+0.00 6
+0.000 7
BAR METER Bar graph 8
DIRECT Direct value. Decimal point location and units of measure
are the same as for the source signal.
Note: Parameters 3402, 3403 and 3405…3407 are not
effective.
9
3405 OUTPUT1
UNIT
Selects the unit for the displayed signal selected by
parameter 3401 SIGNAL1 PARAM.
Note: Parameter is not effective if parameter 3404
OUTPUT1 DSP FORM setting is DIRECT.
Note: Unit selection does not convert values.
Depends
on the
signal
selected
with par.
3401
NO UNIT No unit selected 0
A ampere 1
Vvolt 2
Hz hertz 3
% percent 4
s second 5
h hour 6
rpm revolutions per minute 7
kh kilohour 8
°C celsius 9
lb ft pounds per foot 10
mA milliampere 11
mV millivolt 12
kW kilowatt 13
Wwatt 14
kWh kilowatt hour 15
°F fahrenheit 16
hp horsepower 17
MWh megawatt hour 18
All parameters
No. Name/Value Description Def/FbEq
3404 value Display Range
+/-0 +
3 -32768…+32767
+/-0.0 +
3.1
+/-0.00 +
3.14
+/-0.000 +
3.142
+0 3 0…65535
+0.0 3.1
+0.00 3.14
+0.000 3.142
