246 Actual signals and parameters
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
4035 PID OUT
FREEZE
Freezes the output of the process PID controller. This
feature is useful when the reference is based on a process
actual value connected to an analog input, and the sensor
must be serviced without stopping the process.
The output of the PID controller is frozen as long as the
selected digital input is ON for parameter values DI1…DI5
or OFF for parameter values DI1(INV)…DI5(INV).
See also parameter 4034.
NOT SEL
NOT SEL Not selected 0
DI1 Output is frozen on the rising edge of digital input DI1. 1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
DI1(INV) Output is frozen on the falling edge of digital input DI1. -1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
4036 INTERNAL
SETPNT2
Selects a constant value as the process PID controller
reference, which becomes active when parameter 4010
SET POINT SEL value is set to INTERNAL and setpoint 2 is
selected with the input defined by parameter 4039 INT
SETPNT SEL.
40.0
x…x Unit and range depend on the unit and scale defined by
parameters 4006 UNITS and 4007 UNIT SCALE.
-
4037 INTERNAL
SETPNT3
Selects a constant value as the process PID controller
reference, which becomes active when parameter 4010
SET POINT SEL value is set to INTERNAL and setpoint 3 is
selected with the input defined by parameter 4039 INT
SETPNT SEL.
40.0
x…x Unit and range depend on the unit and scale defined by
parameters 4006 UNITS an
d 4007 UNIT SCALE.
-
4038 INTERNAL
SETPNT4
Selects a constant value as the process PID controller
reference, which becomes active when parameter 4010
SET POINT SEL value is set to INTERNAL and setpoint 4 is
selected with the input defined by parameter 4039 INT
SETPNT SEL.
40.0
x…x Unit and range depend on the unit and scale defined by
parameters 4006 UNITS and 4007 UNIT SCALE.
-
