292 Fieldbus control with the embedded fieldbus
1604 FAULT
RESET SEL
COMM Enables fault reset through
fieldbus 0301 FB CMD WORD 1
bit 4 (with ABB drives profile 5319
EFB PAR 19 bit 7).
40001 bit 7 40031 bit 4
1606 LOCAL
LOCK
COMM Local control mode lock signal
through 0301 FB CMD WORD 1
bit 14
- 40031 bit
14
1607 PARAM
SAVE
DONE
SAVE...
Saves parameter value changes
(including those made through
fieldbus control) to permanent
memory.
41607
1608 START
ENABLE 1
COMM Inverted Start enable 1 (Start
disable) through 0302 FB CMD
WORD 2 bit 18
- 40032 bit
18
1609 START
ENABLE 2
COMM Inverted Start enable 2 (Start
disable) through 0302 FB CMD
WORD 2 bit 19
- 40032 bit
19
LIMITS ABB DRV DCU
2201 ACC/DEC
1/2 SEL
COMM Acceleration/deceleration ramp
pair selection through 0301 FB
CMD WORD 1 bit 10
- 40031 bit
10
2209 RAMP
INPUT 0
COMM Ramp input to zero through 0301
FB CMD WORD 1 bit 13 (with ABB
drives profile 5319 EFB PAR 19 bit
6)
40001 bit 6 40031 bit
13
COMMUNICATION FAULT FUNCTIONS ABB DRV DCU
3018 COMM
FAULT FUNC
NOT SEL
FAULT
CONST SP
7
LAST
SPEED
Determines drive action in case
fieldbus communication is lost.
43018
3019 COMM
FAULT TIME
0.1…60.0 s Defines the time between
c
ommunication loss detection and
the action selected with parameter
3018 COMM FAULT FUNC.
43019
PID CONTROLLER REFERENCE SIGNAL SOURCE SELECTION ABB DRV DCU
4010/
4110/
4210
SET POINT
SEL
COMM
COMM+AI1
COMM*AI1
PID control reference (REF2) 40003 for REF2
Parameter Setting for
fieldbus
control
Function/Information Modbus register
address
