Parameters 115
06.19 Speed control status
word
Speed control status word.
This parameter is read-only.
--
0000h…FFFFh Speed control status word. 1 = 1
06.20 Constant speed status
word
Constant speed/frequency status word. Indicates which
constant speed or frequency is active (if any). See also
parameter 06.19 Speed control status word, bit 7, and
section Constant speeds/frequencies.
This parameter is read-only.
-
0000h…FFFFh Constant speed/frequency status word. 1 = 1
No. Name/Value Description Default
FbEq 16
Bit Name Description
0 Zero speed 1 = Drive is running at zero speed
1Forward
1 = Drive is running in forward direction above zero speed limit
(par. 21.06)
2 Reverse
1 = Drive is running in reverse direction above zero speed limit
(par. 21.06)
3 Out of window Speed out of speed window
4 Internal speed feedback Estimate used for motor control
5 Encoder 1 feedback Encoder 1 feedback used for motor control
6 Encoder 2 feedback Encoder 2 feedback used for motor control
7
Any constant speed
request
1 = A constant speed or frequency has been selected; see par.
06.20 below.
8
Follower speed
correction min lim
Minimum limit of speed correction is reached by speed
controlled follower application.
9
Follower speed
correction max lim
Maximum limit of speed correction is reached by speed
controlled follower application.
10...15 Reserved
Bit Name Description
0 Constant speed 1 1 = Constant speed or frequency 1 selected
1 Constant speed 2 1 = Constant speed or frequency 2 selected
2 Constant speed 3 1 = Constant speed or frequency 3 selected
3 Constant speed 4 1 = Constant speed or frequency 4 selected
4 Constant speed 5 1 = Constant speed or frequency 5 selected
5 Constant speed 6 1 = Constant speed or frequency 6 selected
6 Constant speed 7 1 = Constant speed or frequency 7 selected
7…15 Reserved
