Parameters 125
11.47 Freq in 2 scaled value Displays the value of frequency input 1 after scaling. See
parameter 11.50 Freq in 2 min.
This parameter is read-only.
-
-32768.000…
32767.000
1 = 1
11.50 Freq in 2 min Defines the minimum value for frequency input 2. 0 Hz
0 … 16000 Hz 1 = 1 Hz
11.51 Freq in 2 max Defines the maximum value for frequency input 2. 16000 Hz
0 … 16000 Hz 1 = 1 Hz
11.52 Freq in 2 at scaled min Defines the real value that corresponds to the minimum
frequency input 2 value defined by parameter Freq in 2
min.
0
-32768 … 32767 1 = 1
11.53 Freq in 2 at scaled
max
Defines the real value that corresponds to the maximum
frequency input 2 value defined by parameter Freq in 2
max.
1500
-32768 … 32767 1 = 1
11.54 Freq out 1 actual value Displays the value of frequency output 1 after scaling. See
parameter 11.58 Freq out 1 src min.
This parameter is read-only.
-
0 … 16000 Hz 1 = 1 Hz
11.55 Freq out 1 source Selects a signal to be connected to frequency output 1. Motor speed
used
Not selected None 0
Motor speed used 01.01 Motor speed used 1
Output frequency 01.06 Output frequency 3
Motor current 01.07 Motor current 4
Motor torque 01.10 Motor torque 6
DC voltage 01.11 DC voltage 7
Output power 01.13 Output power 8
Speed ref ramp in 23.02 Speed ref ramp input 10
Speed ref ramp out 23.01 Speed ref ramp output 11
Speed ref used 24.01 Used speed reference 12
Torque ref used 26.02 Torque reference used 13
Freq ref used 28.02 Frequency ref ramp output 14
Process PID out 40.04 Process PID deviation actual 16
Temp Sensor 1
Excitation
35.11 Temperature 1 source 20
Temp Sensor 2
Excitation
35.21 Temperature 2 source 21
Other Source selection (see Terms and abbreviations). -
11.58 Freq out 1 src min Defines the real value of the signal (selected by parameter
11.55 Freq out 1 source and shown by parameter 11.54
Freq out 1 actual value) that corresponds to the minimum
value of frequency output 1 (defined by parameter 11.60
Freq out 1 at src min).
0
No. Name/Value Description Default
FbEq 16
