260 Parameters
49.04 Communication loss
time
Sets a timeout for control panel (or PC tool)
communication. If a communication break lasts longer
than the timeout, the action specified by parameter 49.05
Communication loss action is taken.
10.0 s
0.1…3000.0 s Panel/PC tool communication timeout. 10 = 1 s
49.05 Communication loss
action
Selects how the drive reacts to a control panel (or PC tool)
communication break.
Fault
No action No action taken. 0
Fault Drive trips on 7081 Control panel loss.1
Last speed Drive generates an A7EE Panel loss warning and freezes
the speed to the level the drive was operating at. The
speed is determined on the basis of actual speed using
850 ms low-pass filtering.
WARNING! Make sure that it is safe to continue
operation in case of a communication break.
2
Speed ref safe Drive generates an A7EE Panel loss warning and sets the
speed to the speed defined by parameter 22.41 Speed ref
safe (or 28.41 Frequency ref safe when frequency
reference is being used).
WARNING! Make sure that it is safe to continue
operation in case of a communication break.
3
49.06 Refresh settings Applies the settings of parameters 49.01…49.05.
Note: Refreshing may cause a communication break, so
reconnecting the drive may be required.
Done
Done Refresh done or not requested. 0
Configure Refresh parameters 49.01…49.05. The value reverts
automatically to Done.
1
49.19 Basic panel home
view 1
Selects the parameters that are shown in Home view 1 of
the integrated or Basic panel (ACS-BP-S).
Zero
Zero Shows the factory default parameters. 0
Motor speed used 01.01 Motor speed used 1
Frequency output 01.06 Output frequency 3
Motor current 01.07 Motor current 4
Motor current % of
motor nominal
01.08 Motor current % of motor nom 5
Motor torque
01.10 Motor torque 6
DC voltage 01.11 DC voltage 7
Output power 01.14 Output power 8
Speed ref ramp in 23.01 Speed ref ramp input 10
Speed ref ramp out 23.02 Speed ref ramp output 11
Speed ref used 24.01 Used speed reference 12
Freq ref used 28.02 Frequency ref ramp output 14
Process PID out 40.01 Process PID output actual 16
Temp sensor 1
excitation
The output is used to feed an excitation current to the
temperature sensor 1, see parameter 35.11 Temperature
1 source. See also section Motor thermal protection
(page 92).
20
No. Name/Value Description Default
FbEq 16
