Actual signals and parameters
130
0…10000 Setting range. 1 = 1
90.09 DATA 5 WORD 3 Pointer for the parameter to which the value of the fieldbus is written.
0…10000 Setting range. 1 = 1
92 DATASET OUTPUT SEL
Addresses of the parameters that are to be sent over the fieldbus.
Refer to the Table 2 on page 147 for more default information.
92.01 DATA 2 WORD 1 Pointer for the parameter that is sent over the fieldbus.
0…10000 Setting range. 1 = 1
92.02 DATA 2 WORD 2 Pointer for the parameter that is sent over the fieldbus.
0…10000 Setting range. 1 = 1
92.03 DATA 2 WORD 3 Pointer for the parameter that is sent over the fieldbus.
0…10000 Setting range. 1 = 1
92.04 DATA 4 WORD 1 Pointer for the parameter that is sent over the fieldbus.
0…10000 Setting range. 1 = 1
92.05 DATA 4 WORD 2 Pointer for the parameter that is sent over the fieldbus.
0…10000 Setting range. 1 = 1
92.06 DATA 4 WORD 3 Pointer for the parameter that is sent over the fieldbus.
0…10000 Setting range. 1 = 1
92.07 DATA 6 WORD 1 Pointer for the parameter that is sent over the fieldbus.
0…10000 Setting range. 1 = 1
92.08 DATA 6 WORD 2 Pointer for the parameter that is sent over the fieldbus.
0…10000 Setting range. 1 = 1
92.09 DATA 6 WORD 3 Pointer for the parameter that is sent over the fieldbus.
0 …10000 Setting range. 1 = 1
95 HARDWARE SPECIFIC
Fan speed control, sine filter application etc.
95.01 FAN SPD CTRL MODE Selects the speed control of the optional inverter cooling fan.
CONST 50 Hz Fan is running at constant frequency of 50 Hz when powered. 0
RUN/STOP Drive stopped: Fan is running at constant frequency of 10 Hz.
Drive running: Fan is running at constant frequency of 50 Hz.
1
CONTROLLED The speed of the fan is determined from IGBT temperature vs. fan
speed curve.
2
95.05 ENA INC SW FREQ Activates the minimum switching frequency limitation for Ex-motor
applications.
NO Inactive. 0
YES Active. Minimum switching frequency limit is set to 2 kHz. Used with
motors with an ATEX certification based on 2 kHz minimum switching
frequency.
65535
No. Name/Value Description FbEq
